Details:
Outdoor unit dimensions: 26 3/4"W x 39 5/16"L x 13 11/16"H
Plenum (ceiling assembly) unit dimensions: 21 1/8"W x 21 15/16"L x 1 11/16"H
Direct replacement for 14" x 14" fan
Colors: black and white
Non-ducted
Decibels:
Indoor High speed: 59.7
Indoor Low speed: 55.4
Outdoor: 71.9
2-year manufacturer warranty
Minimum roof thickness is 3", maximum roof thickness is 5 5/16”
Best installed on a flat roof - less than 5 degrees inclination
Works with the ducted system already in place on your RV.
Does not work with the existing thermostat. Will need to use the included thermostat.
Technical Data:
Power supply: 115V/60Hz
Refrigerant charged: R410A/470g
Rated cooling capacity: 13500BTU/H
Input needed for cooling: 1300W
Rated current for cooling: 12Amp
Maximum power input: 1550W
Maximum current: 14Amp
Maximum design pressure: 550PSIG
Minimum design pressure: 236PSIG
CFM (high speed): 375
Installed weight: approx. 73.7 pounds
