Product Description
How to installation:
1.Gauge May Be Mounted In 2"/52mm Dia holes Or In Auto Gauge Custom Mounted Panels .Secure Gauge With Mounting Clamps Supplied.
2.Drill 3/8" Dia .Holes And Install Rubber Grommets Where Pressure Or Vacuum Line Passes Through Sheet Mental Such As Firewall.
3.Attach Nylon Pressure Line To Fitting On Back Of Gauge Using Adaptor ,Ferrule ,And Compression nut .Route Line Through Grommets To Engine Compartment .Connect Line To Pressure port On Engine By Using 1/8" Adaptor Ferrule And Compression Nut For Turbo And Prossure Gauge Or 1/8" Adaptor And Fitting For Vacuum Gauge.
4.Start Engine And Thoroughly Check Installation For Leaks. Twist In Light Socket Assembly And Connect One Wire(Yellow) To Dash Lighting Circut Or Other 12V Power Source And The Other Wire(Black) To A Good Ground.
Package includes:
1 x Water Temp Gauge
1 x Water Temp Sensor
|
|
|
|
|---|---|---|
|
Smoke tint lens during the day,Clear and bright LED Display during the night. |
High quality movement Make product measurements more accurate, Faster measurement, pay attention to your car in real time |
Configure the LED to light up, cool and bright, and watch more clearly in Night |
 |
 |
 |
 |
 |
 |
|
|---|---|---|---|---|---|---|
| Blue Light Water Temp Fahrenheit | Blue Light Voltage | Red Light Oil Pressure | White Light Water Temp | Blue Light Tachometer | Gauge Pod Holder | |
| Diameter | 52mm | 52mm | 52mm | 52mm | 52mm | 52mm |
| Light Color | Blue | Blue | Red | White | Blue | Black |
| Power | DC(10-15V) 12V Professional | DC(10-15V) 12V Professional | DC(10-15V) 12V Professional | DC(10-15V) 12V Professional | DC(10-15V) 12V Professional | No |
| With Sensor | Yes | No | Yes | Yes | No | No |
